Support GPU length up to 435 mm
Support CPU cooler height up to 185 mm
Support installing of up to 9 x 120 mm or 8 x 140 mm fans
Support 420 liquid cooler at front, 360 liquid cooler at top and 140 mm liquid cooler at rear
Equipped with snap-fit top, front, and side panels, this case allows for effortless tool-free removal and reinstallation. The panels are reversible, enabling upside-down installation for enhanced customization and convenience.
*Computer parts are not included. Cooling fan may vary among different countries/regions.
White
MODEL
IF8
STRUCTURE DIMENSIONS (L x W x H)
PRODUCT DIMENSIONS (L x W x H)
443 x 243 x 491 mm
PACKAGE DIMENSIONS (L x W x H)
566 x 317 x 530 mm
STRUCTURE THICKNESS
Structure: 0.6 mm / Panels: 0.7 mm
MATERIALS
SPCC, tempered glass, plastic
DRIVE BAYS
3.5" HDD: 1 + 2.5" SSD: 5 / 3.5" HDD: 2 + 2.5" SSD: 4
3.5" HDD: 3 + 2.5" SSD: 3 / 3.5" HDD: 4 + 2.5" SSD: 2
CPU MAX HEIGHT
GPU MAX LENGTH
I/O PANEL
PCI CARD SLOT
FAN SUPPORT
Front: 3 x 120 mm / 3 x 140 mm
Top: 3 x 120 mm / 2 x 140 mm
Rear: 1 x 120 mm 1 x 140 mm
Bottom: 2 x120 mm / 2 x140 mm
LIQUID COOLING SUPPORT
Front: 420 mm, Top: 240 mm, Rear: 140 mm
POWER SUPPLY SUPPORT
NET WEIGHT
