· Striking stand out design
· Support 240 mm liquid cooler on the top
· Support up to 5 x 12 cm fans
· Integrated RGB lighting strip
· Tempered glass on the left and right
*Computer parts are not included. Cooling fan may vary among different countries/regions.
Special-Shaped ATX Support
Double-Panel 4MM Tempered Glass
SPCC 1.2MM
120MM*7Pcs Fans
240MM Liquid Cooler Support
120MM*7pcs Fan
240MM Liquid Cooler Support
MODEL
ZX7
STRUCTURE DIMENSIONS (L x W x H)
N/A
PRODUCT DIMENSIONS (L x W x H)
550 x 230 x 525 mm
PACKAGE DIMENSIONS (L x W x H)
715 x 615 x 325 mm
STRUCTURE THICKNESS
1.2 mm
MATERIALS
SPCC 1.2MM
Left and right panel: tempered glass
FORM FACTOR
ATX / M-ATX
5.25" CD ROM: 0
3.5" HDD: 1
2.5" SSD: 1
CPU MAX HEIGHT
165 mm
GPU MAX LENGTH
310 mm
I/O PANEL
HD AUDIO + USB 3.0 x 1 / USB 2.0 x 1
PCI CARD SLOT
7
FAN SUPPORT
Front: 3 x 120 mm
Top: 2 x 120 mm
Rear: 2 x 120 mm
LIQUID COOLING SUPPORT
Top: 240 mm
POWER SUPPLY SUPPORT
Bottom mount
NET WEIGHT
7.0 kg / 15.43 lb
7.6 kg / 16.76 lb
