B7-E

1STPLAYER Gaming Case

BLACK.SIR series Extended ATX Case.


· Liquid Cooling Support(Fans are Optional)

   FRONT:24cm

· Fans Support: Up to 8 fans

· USB3.0*1+USB2.0*2+HD AUDIO+MIC

· 3.5" HDD:2  2.5" SSD:2

· Front panel&Left Side Panel:Tempered Glass





BLACK.SIR SERIES B7-E

E-ATX Support /Vertical VGA Installation

ASSEMBLY

SHOWCASE +

Model

B7-E

Structure Dimensions(L*W*H)

380*210*440MM

Product Dimensions(L*W*H)

415*210*452MM

Package Dimensions(L*W*H)

508*278*492MM

Structure Thickness

INSIDE:0.5MM&OUTSIDE:0.6MM

Materials

SPCC 0.5/0.6MM

FRONT&LEFT SIDE PANEL:TEMPERED GLASS

Form Factor

E-ATX/ATX/M-ATX/ITX

Drive Bays

5.25”CD ROM:0

3.5”HDD:2

2.5”SSD:2

CPU MAX Height

165MM

VGA MAX Length

370MM

I/O Panel

USB3.0+USB2.0*2+HD AUDIO+MIC

PCI Card Slot

7

Fan Support

FRONT:3*12CM

REAR:1*12CM

TOP:2*12CM

BOTTOM:2*12CM

Liquid Cooling Support

FRONT:240 MM

Power Supply Support

BOTTOM MOUNT(ATX)

Net Weight

5.5KG / 12.1lb

Gross Weight
6.5KG / 14.3lb
