Support installation of up to 8 fans
Support CPU cooler height up to 165 mm
Support GPU length up to 320 mm
Support a 240 mm radiator at the front
Support up to 4 drive bays: 2 x 3.5" HDD + 2 x 2.5" SSD
*Computer parts are not included. Cooling fan may vary among different countries/regions.
Black
MODEL
B7-A
STRUCTURE DIMENSIONS (L x W x H)
330 x 210 x 440 mm
PRODUCT DIMENSIONS (L x W x H)
365 x 210 x 452 mm
PACKAGE DIMENSIONS (L x W x H)
498 x 263 x 422 mm
STRUCTURE THICKNESS
Interior: 0.4 mm
Exterior: 0.5 mm
MATERIALS
SPCC 0.4 / 0.5 mm
Front / Left Panel: Tempered glass
FORM FACTOR
ATX / M-ATX / Mini-ITX
DRIVE BAYS
5.25" CD ROM: 0
3.5" HDD: 2
2.5" SSD: 2
CPU MAX HEIGHT
165 mm
GPU MAX LENGTH
320 mm
I/O PANEL
USB 3.0 + USB 2.0 x 2 + HD AUDIO + MIC
PCI CARD SLOT
7
FAN SUPPORT
Front: 3 x 12 cm
Rear: 1 x 12 cm
Top: 2 x 12 cm
Bottom: 2 x 12 cm
LIQUID COOLING SUPPORT
Front: 240 mm
POWER SUPPLY SUPPORT
Bottom mount
NET WEIGHT
4.3 kg / 9.48 lb
5.2 kg / 11.5 lb
