FD5-M

PC Gaming Case

  • Support up to 6 fans

  • Support GPU length up to 290 mm

  • Support CPU cooler height up to 155 mm

  • Support 240 mm radiator at the top

  • Easy-to-remove dust filter at the top and bottom for optimized airflow

*Computer parts are not included. Cooling fan may vary among different countries/regions.



MODEL

FD5-M

STRUCTURE DIMENSIONS (L x W x H)

420 x 188 x 420 mm

PRODUCT DIMENSIONS (L x W x H)

460 x 188 x 433 mm

PACKAGE DIMENSIONS (L x W x H)

485 x 250 x 525 mm

STRUCTURE THICKNESS

0.5 mm

MATERIALS

SPCC 0.5 mm

Left panel: Tempered glass

FORM FACTOR

M-ATX

DRIVE BAYS

3.5" HDD: 1 + 2.5'' SSD: 2 or 3.5" HDD: 2 + 2.5'' SSD: 1


MAX CPU COOLER HEIGHT

155 mm

MAX GPU LENGTH

290 mm

I/O PANEL

USB 3.0 x 1 + USB 2.0 x 2 + HD Audio

PCI CARD SLOT

5

FAN SUPPORT

Front: 3 x 12 cm

Rear: 1 x 12 cm

Top: 2 x 12 cm

LIQUID COOLING SUPPORT

Top: 24 cm

POWER SUPPLY SUPPORT

Bottom mounted ATX

NET WEIGHT

N.W.: 3.4 kg

GROSS WEIGHT

G.W.: 3.75 kg
